Foot Mount
Foot Mount – Dimensions
Foot Mount
Low-profile foot mount for secure linear fixture installation
Stable base for precise alignment and secure fixing
Robust stainless steel construction
Elongated slots for fine positional adjustment
Compact footprint suited to tight architectural details
Compatible with BXG linear grazer range
Note: Final load capacity depends on substrate and fasteners used.
Applicable to:
BXG 24
BXG 40
BXG 66
BXG 80
✕
‹
›
Downloads
Foot Mount Downloads
Specifications
BX_BXG24_Foot Mount.zip
BX_BXG40_Foot Mount.zip
BX_BXG66_Foot Mount.zip
BX_BXG80_Foot Mount.zip
BXG 24
BXG 40
BXG 66
BXG 80
