90º Fixed Mount — Images & Dimensions
90º Fixed Mount
Rigid right-angle mount for precise, repeatable aiming.
Fixed 90º Bracket
Stainless Steel Construction
Elongated Slots
Compact Footprint
- Fixed 90º bracket for consistent beam orientation.
- Stainless steel construction for durability.
- Elongated slots for accurate installation alignment.
- Compact footprint for discreet architectural mounting.
- Optimised for BXG series linear grazers.
Note: Final aiming depends on substrate flatness and fastener selection.
Applicable To
Validated with the following fixtures
BXG 80
