Window Light

B W

The BXW is a 360° round LED fixture for architectural window frames, delivering a continuous halo of white or coloured light. High-power LEDs and a focused beam add subtle but powerful emphasis to building facades. Powder-coated aluminium, IP66 rated, 8 W — a clean circular profile with simple surface mounting.

Colour RGBW · RGB · DW · W
Beam 360°
Build IP66
Control DMX · SPI · X-Stream

Configure Your Product View Specifications

1 / 2

Specifications Downloads Configurator

Key Specifications · BXW Window Light

Electrical
Power Consumption	8 W
Operating Voltage	24 V DC
Operating Temperature	−10°C to +50°C
Storage Temperature	−20°C to +70°C
Physical
Fixture Dimensions	119 mm (D) × 175 mm (H)
Housing	Aluminium Housing (Anodised / Black / Custom RAL)
Weight	1 kg
Source Life	50,000 hours under normal operating conditions
Connection	2-Core DC Input Cable
Optical
Beam Angle	360°
Colour Range	RGBW RGB DW W
White CCT	2400K 2700K 3000K 3500K 4000K 5000K 6000K
Control
Control Protocols	DMX SPI X-Stream
Ratings
Ingress Rating	IP66
Warranty	5 Years (Extendable Warranty Available)

Note: Specification summary for quick evaluation and layout planning. Colour mode, CCT, control protocol, and housing finish are configurable to suit your window light installation.
