B S 30

Engineered for large-scale architectural and public-space lighting, the BXS30 delivers powerful, precise illumination for façades, monuments, and bridges. Constructed from anodised aluminium with tempered glass and rated IP66/IK07, it features versatile optics, colour options, and control protocols for reliable, high-impact performance.

  • Beam angles 5°*, 10°, 25°, 40°, 10°×35°, 20°×40°, 10°×60°
  • Controls: X-Stream / SPI / DMX / DALI / PWM
  • LED colours: RGBW / RGBA / RGB / Dynamic White / White (2400–6000K)
  • Outdoor build: IP66 / IK07 snoots: Full/Crossed/Half/None mounts: Bracket/Suspension Rod
  • Beam angles
    5°*, 10°, 25°, 40°
    10°×35°, 20°×40°, 10°×60°
  • Controls
    X-Stream / SPI / DMX
    DALI / PWM
  • LED colours
    RGBW / RGBA / RGB
    Dynamic White / White (2400–6000K)
  • Outdoor build
    IP66 / IK07 · anodised aluminium · tempered lens
    Snoots: Full/Crossed/Half/None · Mounts: Bracket/Suspension Rod
BXS 30 Spotlight render

BXS30 Spotlight Key Specifications

BXS30 At a Glance Overview
  • Dimensions: Ø165mm × 223mm (with bracket), 3kg, die-cast aluminium housing
  • LED Colours: RGB, RGBW, RGBA, Static White (2400K–6000K), Dynamic White (2200K–5000K)
  • Beam Angles: 5°, 10°, 25°, 40°, 20×40°, 10×35°, 10×60°, 30×60°
  • Mounting Options: Bracket, Landscape Spike, with accessory lens and hoods
  • Control Protocols: X-Stream (via PXT/PXR), DMX512, DALI, SPI, PWM
BXS 30 Half Snoot Dimensions
BXS 30 Full Snoot Dimensions
BXS 30 No Snoot Dimensions

BXS30 Spotlight Key Specifications

BXS30 At a Glance Overview
  • Dimensions: Ø165mm × 223mm (with bracket), 3kg, die-cast aluminium housing
  • LED Colours: RGB, RGBW, RGBA, Static White (2400K–6000K), Dynamic White (2200K–5000K)
  • Beam Angles: 5°, 10°, 25°, 40°, 20×40°, 10×35°, 10×60°, 30×60°
  • Mounting Options: Bracket, Landscape Spike, with accessory lens and hoods
  • Control Protocols: X-Stream (via PXT/PXR), DMX512, DALI, SPI, PWM
BXS 30 Half Snoot Dimensions
BXS 30 Full Snoot Dimensions
BXS 30 No Snoot Dimensions

BXS30 Spotlight Key Specifications

BXS30 At a Glance Overview
  • Dimensions: Ø165mm × 223mm (with bracket), 3kg, die-cast aluminium housing
  • LED Colours: RGB, RGBW, RGBA, Static White (2400K–6000K), Dynamic White (2200K–5000K)
  • Beam Angles: 5°, 10°, 25°, 40°, 20×40°, 10×35°, 10×60°, 30×60°
  • Mounting Options: Bracket, Landscape Spike, with accessory lens and hoods
  • Control Protocols: X-Stream (via PXT/PXR), DMX512, DALI, SPI, PWM
BXS 30 Half Snoot Dimensions
BXS 30 Full Snoot Dimensions
BXS 30 No Snoot Dimensions

BXS 30 Spotlight Downloads

Specifications

BXS30_Spotlight_Specifications_Sheet.pdf

BXS30 Accessories

Mounting and glare-control components designed for the BXS30 Beam Spotlight.

BXS30 — Bracket

Bracket

BXS30 — Adjustable mounting bracket for secure wall/surface installation.
BXS30 — Landscape Spike

Landscape Spike

BXS30 — Heavy-duty in-ground spike for landscape mounting.

BXS30 — Half Snoot

Half Snoot

BXS30 — Directional shield for partial glare control and beam cut-off.
BXS30 — Full Snoot

Full Snoot

BXS30 — Deep cylindrical snoot for comprehensive glare suppression.
BXS30 — Suspension Rod System

Suspension Rod System

BXS30 — Ceiling rod kit enabling clean suspended installations.
